3x380V/50Hz CE

Edge banding material on roll 0.4–3.0 mm
Panel height 8–45 mm

Control panel with LCD screen
- manually adjustable pressure bar
- chain feed
- infrared lamp
- pre-milling with diamond cutters
- glue unit for 1 kg EVA granules
- pressure unit with 2 rollers, manually adjustable
- miter saw unit with 1 motor, manual adjustment up to 45°
- Multifunctional flat, bevel, and radius milling unit
- Corner rounding unit
  (up to workpiece height 30 mm) R=2 mm
- Radius scraper
- Flat scraper
- Exhaust connection: 7 x 60 mm,
airflow 1700 m³/h, air velocity 20 m³/h
